| describe | Single column | Double column |
|---|---|---|
| Platform length (m) | 3.0-10.3 | 8.6-23.6 |
| Platform width (m) | 1.5-2.5 | 1.5-2.5 |
| Standard pitch (m) | ----- | 7.3-13.3 |
| Wall spacing (m) | 6 | |
| Large independent height (m) | 15 | 15 |
| Large installation height (m) | 150 | 150 |
| Standard section type | 700X700X1508 | 700X700X1508 |
| Bearing the number | 3 | 6 |
| Lifting speed (m/min) | 6 | 6 |
| Rated load (kg) | 2000 | 2000 |
| Installation height of wall 1 (m) | 3 | 3 |
| Installation height of the second wall (m) | 9 | 9 |
| Large height of jack (m) | 0.6-0.72 | 0.6-0.72 |
| Distance from the bottom of main engine to the fence (m) | 1.95 | 1.95 |
| Bottom end of main engine to platform pedal height (m) | 0.83 | 0.83 |
| Height of main fence (m) | 2 | 2 |
| Motor number | 2 | 4 |
| Motor rating | 2X2.2KW | 4X2.2KW |
| Starting rated current | ±60A | ±120A |
| Supply voltage/frequency | 380-415V/50HZ；440-460V/60HZ | |
| A fuse | 16A | 25A |
| The control voltage | 42Vac | |
